High-Performance Connectivity for Logix Family Controllers
This driver is included in the following TOP Server driver suites:
Channels and devices per channel.
Max configurable packet size.
Elements per single array request.
Parallel communication threads.
The Rockwell Allen-Bradley ControlLogix Ethernet driver works in conjunction with TOP Server to provide data exchange between OPC UA, OPC DA, SuiteLink and DDE clients and Allen-Bradley Logix Family controllers via the Allen-Bradley ControlLogix Ethernet protocol and even legacy controllers via gateway support.
Advanced features such as ControlLogix Gateway support and NET-ENI support allow the ControlLogix Ethernet driver to connect, not only to Logix controllers, but also to legacy PLC-5 and SLC Family controllers. The ControlLogix Ethernet driver is a multi-threaded high performance driver for simultaneous communication with multiple PLCs using multiple channels.
This driver does not require a Rockwell Automation RSLinx license.
Proven benefits that help you deploy faster and operate more reliably
Compatible with most firmware revisions, refer to the latest supported firmware details for specifics. Open address range support ensures compatibility with PLC 5, SLC 500, and MicroLogix controllers, including ENI and ControlLogix Gateway applications.
ControlLogix native tag addressing is supported, along with user defined tags. Arrays are supported for all atomic data types, enabling flexible and scalable data structures.
Supports all file types, including output, input, and integer. Data types such as float, long word, and BCD are supported depending on file type, along with numerous predefined types and locale specific multi byte strings.
Optimized memory access improves performance across all tags and data types. Communication uses a standard Ethernet network interface card with TCP and IP protocols.
