TOP Server Mitsubishi CNC Ethernet OPC Driver Details

Mitsubishi CNC Ethernet Key Features Include

• Maximum Number of Channels & Devices:
  • Channels - 256
  • Devices per Channel - 255
  • NOTE: Practical channel/device limits will vary depending on your available system resources
• PC number support for network bridging
• Uses AJ71E71 family of communications cards
• Memory Types Supported: X, Y, M, B, L, F, TS, TC, TN, CS, CT, CN, D, W, R
• Support for Q specific Memory Types: DX, DY, SB, Sm, V, SS, SC, SN, SD, SW, Z
• Supports all data types

Standard Mitsubishi CNC Ethernet Features Include

• Memory Types Supported: X, Y, M, B, L, F, TS, TC, TN, CS, CT, CN, D, W, R
• Support for Q specific Memory Types: DX, DY, SB, Sm, V, SS, SC, SN, SD, SW, Z
• Supports all data types
• TOP Server Built-In Features:
  • Multi-threaded architecture for high scalability
  • Runtime changes via wizard-based configuration interface with intuitive Properties Editor
  • Secure User Management
  • Built-in Device/Network Redundancy
  • Auto-Demotion (Slow Polling)
  • Extensive communication and server diagnostics (OPC / Communications / Event Log)
  • For all TOP Server built-in features, click here.

Mitsubishi CNC Ethernet Advanced Features Include

• Optimized communications allow each device to have a separate thread/channel of communications (up to 256 devices)
• Specify a Network Interface Card at the channel level (Details)
• User-selectable socket connection termination on device response timeout

Mitsubishi CNC Ethernet Supported Devices (Don't See Your Device Listed?  Contact Us)

• C64 CNC Controllers

Mitsubishi CNC Ethernet Supported Protocols / Networks

• Protocols:
  • MELSEC
• Networks:

  • UDP Ethernet
